Engineering Design Portfolio
Aquaculture
Simple fluid components
Grows algae for food & fuel
High efficiency LED grow lights
Prototyping in progress
Upgraded lighting design
First culture test
Spirulina grown & tasted :)
Next-generation consumer product
Aeroponics
I was responsible for lighting, irrigation, and HVAC
Racks were adjustable for different crop heights
I packaged HVAC, CO2, and fertigation systems under the floor vents
A transparent dual-layer membrane enclosed the crop growth environment
Photovoltaics
Using mirror film to increase solar cell output
Cell protection and mounting
Cell arrays and connections
Up to 27.6W max capacity, plenty for phones and portable batteries
Systems take solar energy and deliver 120V AC outlets
Harvest daylight to electricity
Website coming soon
Thermoelectrics
Product uses a thermoelectric generator to help cool electronics, while making electricity
Proof of concept to measure efficiency of the Peltier module
Initial CAD, made with the help of an artist
Shows electronic unit, TEG, and cold plate
Product Design
Curved monitor application for flexible OLED screens
Shows arc length for optimal viewing distance
Office environment rendering, made with the help of an artist
Exhibits additional features, integrating further technologies
NX CAD Practice
Features, assembly.
Surfaces, assembly.
Surfaces, features, assembly.
Satellite
Unfolded view
Exploded view
Folded view
Rendering
Rocket
Concept sketch
CAD model
CAD rendering
Rough prototype
Avionics
Potting (using epoxy to protect electronics) a data logger PCB directly to its box. This yielded a natural frequency that was too low.
Incorporating a seal, enclosure, and mounting legs for the data logger circuit. The SD card is still protected by epoxy potting.
At 200g of force, the maximum stress is only 13.1 MPa, compared to the yield stress of Aluminum 7075 of 503 MPa.
At 50g RMs of random vibration, the maximum stress is 30.7 MPa, still small compared to the yield stress of Aluminum 7075 of 503 MPa.
Added improved mounting features, and an o-ring for better sealing.
The final design, with separate seal screws from the mounting screws, a heat sink to cool the microchip, better mounting features, ribs and fillets.
The final design, with separate seal screws from the mounting screws, a heat sink to cool the microchip, better mounting features, ribs and fillets.
The final product, "Feather."
Hovercraft
Concept sketch
Concept sculpture
CAD model
Foam and clay model
Rough prototype
Revised CAD rendering
Revised prototype
It worked!
Industrial
Concept sketch
CAD model
CAD rendering
CAD rendering
Tool
Concept sketch
CAD model
Concept sketch
CAD model
Structural
Concept sketch
CAD model
Finite Element Analysis (FEA) deformation simulation
Engineering drawing
